问卷调查李克特五级量表发散柱状图 (Likert Scale Diverging Bar)

经管社科与文科问卷量表分析标准图表，以0轴为中心左右发散展示同意度与反对度比例分布。

🔬 矢量预览 (Vector Preview) 600 DPI Ready

问卷调查李克特五级量表发散柱状图 (Likert Scale Diverging Bar)

格式支持: SVG, PDF, PNG (600 DPI), TIFF

⚡ 在线工作台出图 (Wasm) 📥 下载当前 SVG 📥 示例 CSV 🎓 15分钟人工加急 (¥39起)

📊 统计学特性 (Statistical Features)

✓ 李克特五级量表发散累计
✓ 中心零轴中立对齐
✓ 正负倾向百分比分割
✓ 均值与满意度统计

🛡️ QC 质检要点 (QC Highlights)

✓ 题项长文本标签换行对齐
✓ 负向红橙 vs 正向蓝绿区分鲜明
✓ 百分比数字不与柱体冲突
✓ 符合毕业论文排版规范

🎨 顶刊色彩提取器 (Palette Extractor)Nature

Crisp sans-serif typography, clean borderless spines, high-contrast palette with soft muted secondary accents.

🛡️ 无障碍评分:AAA (Deuteranopia & Protanopia Compliant)

📋 Data Contract 数据契约规范 Strict Schema

输入数据必须完全符合下列列名与数据类型规范，方可通过自动化数据前检 (Pre-flight Validation)。

📥 下载规范示例 CSV 数据

字段名称 (Column)	数据类型 (Type)	约束性	语义说明与值域约束
question	categorical	必需 (Required)	问卷题项/量表维度名称
strongly_disagree	continuous	必需 (Required)	非常不同意比例 (%)
disagree	continuous	必需 (Required)	不同意比例 (%)
neutral	continuous	必需 (Required)	中立比例 (%)
agree	continuous	必需 (Required)	同意比例 (%)
strongly_agree	continuous	必需 (Required)	非常同意比例 (%)

组内最小样本量: n ≥ 2

最大允许缺失率: 0%

🐍 独立可复现 Python 绘图源码 Stand-alone Script

完全可复现的 Python 脚本，支持 CLI 参数 `--data`, `--style`, `--output-dir` 与模块化 `render()` 调用。
